System Specifications

Standard

Compliant with HomePlug AV2

IEEE 1901 and HomePlug AV standard

Powerline Data Rate

Transmit: up to 1800 Mbps*

Receive: up to 1800 Mbps*

Access Methods

CSMA/CA channel-access schemes

HomePlug Modulation

OFDM symbol modulation

QAM 4096/1024/256/64/16

QPSK, BPSK, ROBO carrier modulation schemes

Range

Max. range up to 300 meters over power line

Security

128-bit AES encryption

Quality of Service (QoS)

Supports up to 4-level type QoS

Frequency Band

2 MHz to 86 MHz

IGMP

IGMP v1/v2/v3

System Requirements

Operating system independent:

Ethernet: RJ-45

Utility software OS support:

Microsoft Windows XP/Vista/7/8

Hardware Specifications

Ethernet interface: Two 10/100/1000 Mbps RJ-45 connectors with auto MDI/MDIX support

LED indicators:

Powerline network quality:

Green: Best

Amber: Better

Red: Good

Ethernet link/activity

Button:

Encrypt/Reset button

Power rating: 100 to 240 V AC, 50/60 Hz

Power consumption:

Full operation: 6 watt max.

Socket/Connector:

EU:

Type F (CEE 7/4)/Type F (CEE 7/4)

Max power rating: 16 A 250 V ~

DE, NL, ES, PT, AT, SE, FI, NO, GR, HU, LU

UK:

Type G (BS 1363)/Type G (BS 1363)

Max power rating: 13 A 250 V~

UK, CY, HK

US:

Type B (NEMA 5-15)/Type B (NEMA 5-15)

Max power rating: 15 A 120 V~

CH:

Type J CEE 7/16/Type J CEE 7/16

Max power rating: 10 A 250 V~
