Throughout11.9Mpps

Backbound Bandwidth16Gbps / non-blocking

Power Consumption<4 watts

Power Requirements100-240V AC, 50/60Hz

Power Adapter9V DC, 1A

Switch Processing SchemeStore-and-Forward

Address Table4K entries

Jumbo packet size9K

Flow ControlBack pressure for half duplex, IEEE 802.3x pause of frame for full duplex

Dimension186.7mm×106.7mm×33.3mm(W x D x H)

Weight<1kg

CertificationFCC , CE , ROHS

Standard&ProtocolIEEE 802.3

IEEE 802.3u

IEEE 802.3ab

IEEE 802.3x

PortLoop Detection/Prevention

Inductive Lightning Protection: 4KV

TemperatureOperating: 0~50 degrees C

Storage: -10~70 degrees C

HumidityOperating: 5~95%

Storage: 5~95% (Non-condensing)
